BVS-F2W 10.1 Inch Rugged Tablet Intel N100 , Waterproof Dustproof Shockproof, 8000mAh Battery, 8GB+128GB, GPS, NFC, 4G/5G LTE, Industrial Grade Tablet
- Military-Grade Protection IP65 Certified: Total dust ingress protection & water jet resistance，1.2m (4ft) Drop Survival onto concrete (MIL-STD-810H compliant)，Extended Temp Range: Operates at -20°C to 60°C (-4°F to 140°F)，±12kV ESD protection & 95% humidity tolerance
- Elite Processing Power Intel Alder Lake N100，Intel Iris Xe Graphics for CAD/3D applications，8GB LPDDR4 RAM ，128GB Removable SSD
- Sunlight-Readable Display 10.1" IPS (1920×1200) @ 550 nits (Optional 1000-nit for direct sun)，10-point Projected Capacitive Touch (G+F+F)，Glove & Wet Hand Support
- Enterprise-Grade I/O 1× USB 3.0 + HDMI 1.4 + Gigabit RJ45，RS232 DB9 Serial Port (Full 9-pin) + 3.5mm Audio，1 x SIM Slots + MicroSD (128GB max)
Description
Specifications
【Model】BVS-F2W
【Item】BVS-F2W 10.1 Inch Rugged Tablet Intel 13th Gen N100 , Waterproof Dustproof Shockproof, 8000mAh Battery, 8GB+128GB, GPS, NFC, 4G/5G LTE, Industrial Grade Tablet
【Parameter List】
| Basic Parameters | Product Model | 101-F2W |
| Description | Windows 10.1" Rugged Tablet | |
| Weight | Net 1150g | |
| Keys | Power, Volume +/-, Custom keys, Shortcut keys | |
| Screen Size | 10.1" 16:10 IPS | |
| Resolution | 1200(H) x 1920(V) | |
| Brightness | Standard 550cd/㎡, Optional 700/1000cd/㎡ | |
| Touch Panel | Capacitive, 10-point (G+F+F), supports glove & wet hand mode, customizable EMR/Anti-glare/Anti-reflection/Shockproof/Special screen |
|
| Battery | 7.6V/8000mAh (removable gel polymer Li-battery) | |
| Camera | Front 5.0MP, Rear 8.0MP with autofocus | |
| Speaker & Mic | Built-in 8Ω/2W*2, waterproof speaker x1 | |
| Hardware Configuration | CPU | Intel Alder Lake N100 |
| GPU | Intel® Iris® Xe Graphics eligible | |
| RAM | 8GB (Optional 16GB) | |
| SSD | 128GB Removable (Optional 256GB) | |
| Gyroscope | Built-in | |
| Accelerometer | Built-in | |
| Compass | Built-in | |
| E-Compass | Built-in | |
| Operating System | Windows 10/11 PRO (Home/IoT) | |
| Network Connectivity | WIFI | WIFI5, supports 4G global/5G module |
| Bluetooth | BT4.2 (BLE) Class1, Range 10m | |
| 4G/5G | Optional | |
| GNSS | Optional | |
| GPS | Optional | |
| RFID | Optional | |
| NFC | Optional | |
| Optional Modules | Barcode/QR Code | Optional |
| High-Precision Positioning | Optional | |
| Fingerprint | Optional | |
| ID Card Reader | Optional | |
| UHF RFID | Optional | |
| I/O Interfaces | USB Ports | USB 3.0 ×1 |
| Headphone Jack | Ø3.5mm standard headphone ×1 | |
| TF Card | Supported, Max 128GB | |
| SIM Card | Single SIM | |
| HDMI | HDMI 1.4 Mini ×1 | |
| DC Port | DC 3.5×1.35mm (optional aviation connector) | |
| POGO PIN | Rear 2-pin, Bottom 11-pin | |
| DB9 Port | ×1 Default pin I/O (RS232/485 DB9 optional) | |
| RJ45 Port | ×1 | |
| Type-C | Default data only | |
| Power & Rugged Features | Power Adapter | AC100–240V input, DC19V/3.42A output |
| Protection Rating | IP67 | |
| Drop Resistance | 0.8m | |
| Operating Temp. | -15°C ~ 50°C | |
| Storage Temp. | -20°C ~ 60°C | |
| Humidity | 95% non-condensing | |
| ESD Protection | ±6kV contact discharge, ±12kV air discharge |
BVS-F2W 10.1 Inch Rugged Tablet Intel N100 , Waterproof Dustproof Shockproof, 8000mAh Battery, 8GB+128GB, GPS, NFC, 4G/5G LTE, Industrial Grade Tablet
$468.99
