BVS GW-H Fanless PC, Industrial Mini Pc , Core i5 5th Gen, 8GB RAM 128GB SSD,HD+VGA，LAN*1，USB*6，RS232/485*2,Full Metal Industrial Fanless Mini PC
- 【Compact & Space-Saving Design】: Measures just 202.4*202.4*48mm , ideal for discreet placement on desks, or mounted on walls/VESA mounts.
- 【Processor & Storage】: Capable performance powered by an Intel Core i5-5th Gen(Core I3、I7 optional) CPU for smooth multitasking. 8GB RAM, 128GB SSD.
- 【I/O Specifications】: Multi-ports likes 2*COM(RS232/485), 6*USB, 1*LAN , 1*HD, 1* VGA
- 【BVS Warranty】 ; We promise 1 years quality warranty and lifelong customer service for the BVS computer, if any questions, please don't hesitate to contact us, we will help you to resolve the problem immediately.
Specifications
【Paramater List】
|
Model |
BVS-GW-H |
|
|
Case
|
Material/Structure |
All aluminum alloy without fan |
|
Color |
Black |
|
|
Dimensions (length, width, height) |
202.4*202.4*48MM |
|
|
Motherboard
|
CPU |
Intel core i5 5th gen |
|
display |
Integrated Intel® Iris™ Graphics supports DirectX 11.1 OpenGL 3.2 |
|
|
RAM |
DDR3L 8G (optional 4G/16G) |
|
|
Front panel interface
|
POWER |
1* Power Switch |
|
USB |
4* USB Interfaces |
|
|
Rear panel interface
|
Display interface |
1*VGA interface, 1*HD/M1 1.4 interface |
|
COM |
2* DB9 serial interface, COM5, COM6 support RS232/RS485 switch |
|
|
USB |
4* USB Interfaces |
|
|
Wi-Fi Terminal (optional) |
2* Wi-Fi ports |
|
|
LAN |
1*Intel® WGI211AT Gigabit network card, support Wake on LAN, PXE function |
|
|
Audio |
2* Audio Interface |
|
|
power supply |
1* DC power adapter interface, supports DC12V power input |
|
|
storage
|
SANTA |
1*2.5 inch hard drive expansion |
|
Solid state drive |
1* MSATA SSD solid state drive expansion, transmission speed up to 6Gbps |
|
|
software support
|
Microsoft Windows |
Win7 (default)/Win10 |
|
Linux |
hardware only, system not included |
|
|
Power requirement
|
Power type |
External power adapter |
|
Voltage input |
DC 12V |
|
|
Power output |
AC TO DC, 36W / 60W (optional) |
|
|
surroundings |
Operating temperature |
-10℃～60℃ |
|
storage temperature |
-20℃～70℃ |
|
|
Relative humidity |
5%-95% relative humidity, non-condensing |
|
|
Job vibration |
0.5g rms/5-500HZ/random/operating |
|
